ASANO (Alat Separator
Sampah Anorganik dan Organik)
ASANO
(Alat Separator Sampah Anorganik dan Organik)
Powered by Electrical Dynamo and Dongfeng Diesel, Asano enchances waste management facilities' capability to efficiently separate mixed waste into organic and non-organic materials
About
Your Waste Sorting Efficiency Solution
Automatically sorting waste
Sorting low-value inorganic waste ready for shredding
Sorting organic material waste into slurry
Product Type
-
ASANO 80
ASANO 80
250 - 500 kg/hour
Spesification
Chasis
Min. UNP 50
Dimensions
Min. 750 x 450 x 1.000 mm
Shaft Diameter
Min. 35mm
Screen Thickness
Min. 3mm
Blade Thickness
8mm
Drive
15 HP Electric Dynamo equipped with SD Panel
-
ASANO 1200
ASANO 1200
400 - 1.000 kg/hour
Spesification
Chasis
Min. UNP 65
Dimensions
Min. 1.150 x 650 x 1.400 mm
Shaft Diameter
Min. 55mm
Screen Thickness
Min. 4mm
Hopper Thickness
3mm
Blade Thickness
10mm
Drive
20 HP Electric Dynamo equipped with SD Panel
-
ASANO 1500
ASANO 1500
1.000 - 1.500 kg/hour
Spesification
Chasis
Min. UNP 80
Dimensions
Min. 1.450 x 650 x 1.800 mm
Shaft Diameter
Min. 65mm
Screen Thickness
Min. 4mm
Hopper Thickness
3 mm
Blade Thickness
10mm
Drive
30 HP Electric Dynamo equipped with SD Panel
-
ASANO 1500S
ASANO 1500S
1.000 - 1.500 kg/hour + Screw
Spesification
Chasis
Min. UNP 80
Dimensions
Min. 1.450 x 650 x 1.800 mm
Shaft Diameter
Min. 65mm
Screen Thickness
Min. 4mm
Hopper Thickness
3 mm
Blade Thickness
10mm
Drive
30 HP Electric Dynamo equipped with SD Panel
-
ASANO 2000
ASANO 2000
1.500 - 2.000 kg/hour
Spesification
Chasis
Min. UNP 80
Dimensions
Min. 1.950 x 650 x 1.800 mm
Shaft Diameter
Min. 65mm
Screen Thickness
Min. 4mm
Hopper Thickness
3 mm
Blade Thickness
10mm
Drive
30 HP Electric Dynamo equipped with SD Panel
-
ASANO 2000S
ASANO 2000S
1.500 - 2.000 kg/hour + Screw
Spesification
Chasis
Min. UNP 80
Dimensions
Min. 1.950 x 650 x 1.800 mm
Shaft Diameter
Min. 65mm
Screen Thickness
Min. 4mm
Hopper Thickness
3 mm
Blade Thickness
10mm
Drive
30 HP Electric Dynamo equipped with SD Panel
ASANO 80
250 - 500 kg/hour
Spesification
Chasis
Min. UNP 50
Dimensions
Min. 750 x 450 x 1.000 mm
Shaft Diameter
Min. 35mm
Screen Thickness
Min. 3mm
Blade Thickness
8mm
Drive
15 HP Electric Dynamo equipped with SD Panel
ASANO 1200
400 - 1.000 kg/hour
Spesification
Chasis
Min. UNP 65
Dimensions
Min. 1.150 x 650 x 1.400 mm
Shaft Diameter
Min. 55mm
Screen Thickness
Min. 4mm
Hopper Thickness
3mm
Blade Thickness
10mm
Drive
20 HP Electric Dynamo equipped with SD Panel
ASANO 1500
1.000 - 1.500 kg/hour
Spesification
Chasis
Min. UNP 80
Dimensions
Min. 1.450 x 650 x 1.800 mm
Shaft Diameter
Min. 65mm
Screen Thickness
Min. 4mm
Hopper Thickness
3 mm
Blade Thickness
10mm
Drive
30 HP Electric Dynamo equipped with SD Panel
ASANO 1500S
1.000 - 1.500 kg/hour + Screw
Spesification
Chasis
Min. UNP 80
Dimensions
Min. 1.450 x 650 x 1.800 mm
Shaft Diameter
Min. 65mm
Screen Thickness
Min. 4mm
Hopper Thickness
3 mm
Blade Thickness
10mm
Drive
30 HP Electric Dynamo equipped with SD Panel
ASANO 2000
1.500 - 2.000 kg/hour
Spesification
Chasis
Min. UNP 80
Dimensions
Min. 1.950 x 650 x 1.800 mm
Shaft Diameter
Min. 65mm
Screen Thickness
Min. 4mm
Hopper Thickness
3 mm
Blade Thickness
10mm
Drive
30 HP Electric Dynamo equipped with SD Panel
ASANO 2000S
1.500 - 2.000 kg/hour + Screw
Spesification
Chasis
Min. UNP 80
Dimensions
Min. 1.950 x 650 x 1.800 mm
Shaft Diameter
Min. 65mm
SScreen Thickness
Min. 4mm
Hopper Thickness
3 mm
Blade Thickness
10mm
Drive
30 HP Electric Dynamo equipped with SD Panel
We are not only offer high quality product & service, but also make sure our product comply with TKDN-certified and listed in the National e-catalog
Optimize your productivity with our Engineering, Procurement & Construction Services!
Design Engineering
Design Facilities with 5M Approach
Construction
Build Sustainable Waste Management Facility
Procurement
Provide Selections of Machine Procurement
Assistance
Operational Assistance
Maintenance
Machine Commissioning & Testing, Maintenance Service
Contact
Our Sales Team
F.A.Q
-
Why should you choose Waste4Change Waste Management Equipment?
Waste4Change offers waste management equipment tested by experienced technicians and TKDN-certified. We also provide a 6-month warranty to ensure the quality and reliability of our products. -
What do you get with the purchase of Waste Management Equipment?
With the purchase of waste management equipment from Waste4Change, you will receive the equipment itself, a comprehensive guidebook, and additional warranty for extra protection. -
Are the listed costs inclusive?
The listed costs do not include 11% VAT and shipping charges. -
Are your solutions compliant with local regulations?
We ensure that all our waste management solutions comply with local, regional, and national regulations and standards. -
What is waste4change's stance on any form of Corruption, Collusion and Nepotism (KKN) practice?
We do not support any form of KKN practice in all waste4change services. -
How do your solutions contribute to sustainability?
Our solutions focus on reducing landfill waste, recycling materials, converting waste to energy, and minimizing environmental impact, thereby promoting sustainable waste management practices. -
Do you collaborate with other organizations?
Yes, Waste4Change actively collaborate with various organizations, including governmental agencies, non-profits, and private companies to improve waste management practices and achieve common sustainability goals. -
How can I get a quote for a waste management project?
You can request a quote by contacting us through our website's contact form, emailing us directly at engineering@waste4change.com, or calling our customer service line. We'll be happy to discuss your needs and provide a detailed proposal.
